Pipes

Pipes and Tubes

Pipes

We offer M.S Pipes and Tubes in real market price for customers. Compare your price with our representative. Also Pipes and Tubes available in different sizes and dimensions and can also be customized as per the requirement. Available items are below listed,

SIZE IN INCHES	NB and Series	Outside Diameter		Wall Thickness		Nominal Weight
		Outside Diameter				Black Pipes		Galvanised Pipes
		Min	Max			Plain End		Screwed & Socked
	mm	mm	mm	mm	SWG	Kg/m	mts/tonne	Kg/m	mts/tonne
1/2"	15L	21.0	21.4	2.0	14	0.95	1052	0.96	1046
	M	21.0	21.8	2.6	12	1.21	826	1.22	820
	H	21.0	21.8	3.2	10	1.44	694	1.45	690
3/4"	20L	26.4	26.9	2.3	13	1.38	725	1.39	719
	M	26.5	27.3	2.6	12	1.56	641	1.57	637
	H	26.5	27.3	3.2	10	1.87	535	1.88	532
1"	25L	33.2	33.8	2.6	12	1.98	505	2.00	500
	M	33.3	34.2	3.2	10	2.41	415	2.43	411.5
	H	33.3	34.2	4.0	8	2.93	341	2.95	339
1-1/4"	32L	41.8	42.5	2.6	12	2.54	394	2.57	389
	M	42.0	42.9	3.2	10	3.1	322	3.13	319
	H	42.0	42.9	4.0	8	3.79	264	3.82	262
1-1/2"	40L	47.8	48.4	2.9	11	3.23	310	3.27	306
	M	47.8	48.8	3.2	10	3.56	281	3.60	278
	H	47.9	48.8	4.0	8	4.37	229	4.41	227
2"	50L	59.6	60.2	2.9	11	4.08	245	4.15	241
	M	59.7	60.8	3.6	9	5.03	199	5.10	196
	H	59.7	60.8	4.5	7	6.19	161	6.26	160
2-1/2"	65L	75.2	76.0	3.2	10	5.71	175	5.83	171.5
	M	75.3	76.6	3.6	9	6.42	156	6.54	153
	H	75.3	76.6	4.2	7	7.93	126	8.05	124
3"	80L	87.9	88.7	3.2	10	6.72	149	6.89	145
	M	88.0	89.5	4.0	8	8.36	120	8.53	117
	H	88.0	89.5	4.8	6	9.9	101	10.40	96
4"	100L	113.0	113.9	3	9	9.75	102	10.00	100
	M	113.1	115.0	4.5	7	12.20	82	12.50	80
	H	113.1	115.0	5.4	5	14.50	69	14.80	67.5
5"	125M	138.50	140.8	4.8	6	15.90	63	16.40	61
	H	138.5	140.8	5.4	5	17.90	56	18.40	54
6"	150M	163.9	166.5	4.8	6	18.90	53	10.50	51
	H	163.9	166.5	5.4	5	21.30	47	21.90	46
